NEMA 3 Enclosures
Installation zone RECOMMENDATION1
1
1
1
OCC's NEMA 3 Wall Mount Enclosures offer the same modular features of the WTC series with the added outdoor durability for outside plant functionality. The NEMA 3 series, like all OCC Wall Mount cabinets, can be ordered empty or can be easily customized to fit any exact specification. Ideal for smaller OSP and inside premise applications, the OCO6N and OCO12N are a perfect fit with the additional benefit of being NEMA Type 3 compliant.
Features
- Accommodates any OCC snap-in adapter plate or cassette modules
- Lockable hasp ideal for any combination padlock
- Fiber storage hoops designed to maintain orderly fiber management included
- Port identification sheets are included
- Mounting hardware included
Specifications
| Download Drawing | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Part Number | Description | Rack Units | Ports | Adapter Plates | Splice Capacity | Splice Kits | DWG/ZIP | ||
| OCO6N | Outdoor / Indoor Wall Mount Cabinet, 6-Port, NEMA 3 Outdoor Rated, Holds 1 Adapter Plate | 6 | 1 | 12 | - | Download | Download | ||
| OCO6NS | Outdoor / Indoor Wall Mount Cabinet, 6-Port, NEMA 3 Outdoor Rated, Holds 1 Adapter Plate, Includes Splice Tray | 6 | 1 | 6 | Splice Block | Download | Download | ||
| OCO12N | Outdoor / Indoor Wall Mount Cabinet, 12-Port, NEMA 3 Outdoor Rated, Holds 2 Adapter Plates | 12 | 2 | - | - | Download | Download | ||
| OCO12NS | Outdoor / Indoor Wall Mount Cabinet, 12-Port, NEMA 3 Outdoor Rated, Holds 2 Adapter Plates, Includes Splice Tray | 12 | 2 | 12 | Splice Block | Download | Download | ||
| 10801301 | 3/4" Conduit Adapter for OCO6N | Download | Download | ||||||
| 10801201 | 1" Conduit Adapter for OCO6N | Download | Download | ||||||
| OCO-NS | Outdoor / Indoor Wall Mount Cabinet, NEMA 3 Outdoor Rated, Includes Splice Tray | 12 | W12S | Download | Download | ||||
