DZ-Series – Plenum Rated Cables
Installation zone RECOMMENDATION1
1
1
1
Offering the durability you expect from OCC, these distribution cables provide all of the indispensable elements needed for Indoor and Indoor/Outdoor commercial applications, while providing great value. Manufactured with Indoor/Outdoor grade low smoke PVC for plenum applications.
Features
- Ease of Termination
- Product in Inventory / Short Lead Time
- Lightweight
- Designed & Manufactured in the USA
- Industry-Leading Fiber Performance Specification
- Manufactured with OCC’s Industry-Leading Polymers
- Covered by OCC's 25yr Channel/Link Limited Warranty
- A Versatile Choice for Indoor/Outdoor Use
- Available in Indoor/Outdoor Riser (OFNR), or Plenum (OFNP)
- Available in 4-24 Fibers
- Colors Available: Aqua, Black, Orange, and Yellow
- ICEA 696 Compliant
- Water Blocked
- -40°C to + 70°C Temperature Range
- RoHS & Reach Compliant
- Bend Insensitive Fibers are Standard
Characteristics
| Characteristic | DZ-Series - Plenum Rated Cables |
|---|---|
| Operating Temp | -40°C to +70°C |
| Storage Temp | -40°C to +70°C |
| Install Temp | -10°C to +60°C |
| Flame Retardancy | UL Listed Type OFN NFPA262 FT6 (CSA C22.2 No. 232) |
| Jacket Type | Indoor / Outdoor Low Smoke PVC |
Specifications
Specifications
| Tensile Load | Minimum Bend Radius | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Fiber Count | Part Number | Spec Sheet | Diameter mm (in) |
Weight kg/km (lbs/1,000ft) |
Installation N (lbs) |
Operation N (lbs) |
Installation cm (in) |
Longer Term cm (in) |
|
| 4 | DZ004T***9*P | Download Spec Sheet |
4.4 (0.17) |
17.0 (12.0) |
660 (150) |
200 (45) |
8.8 (3.5) |
4.4 (1.7) |
|
| 6 | DZ006T***9*P | Download Spec Sheet |
4.4 (0.17) |
19.0 (26.0) |
660 (150) |
200 (45) |
8.8 (3.5) |
4.4 (1.7) |
|
| 8 | DZ008T***9*P | Download Spec Sheet |
4.8 (0.19) |
26.0 (18.0) |
660 (150) |
200 (45) |
9.6 (3.8) |
4.8 (1.9) |
|
| 12 | DZ012T***9*P | Download Spec Sheet |
6.2 (0.24) |
34.0 (23.0) |
660 (150) |
200 (45) |
12.4 (4.9) |
6.2 (2.4) |
|
| 18 | DZ018T***9*P | Download Spec Sheet |
7.4 (0.29) |
48.0 (32.0) |
1,320 (300) |
400 (90) |
14.8 (5.8) |
7.4 (2.9) |
|
| 24 | DZ024T***9*P | Download Spec Sheet |
7.4 (0.29) |
54.0 (36.0) |
1,320 (300) |
400 (90) |
14.8 (5.8) |
7.4 (2.9) |
|
